kubespray部署k8s集群

1. 服务器说明

1.1 节点要求

节点数 >= 3台 CPU >= 2c 内存 >= 2GB 安全组：关闭（允许节点之间任意端口访问，以及ipip隧道协议通讯）

1.2 环境说明

我们使用三台CentOS7.6的虚拟机，具体信息如下：	系统类型	IP地址	节点角色	CPU	Memory	Hostname
centos-7.6	10.211.55.14	master	>=2	>=2G	node-1
centos-7.6	10.211.55.15	master	>=2	>=2G	node-2
centos-7.6	10.211.55.16	worker	>=2	>=2G	node-3

1.3 科学上网

注意：安装过程需要访问很多google、github、docker.io、k8s.io等外网地址 环境中只要有一台作为代理可访问外网即可

服务器需要能够有访问外网的能力，若使用替代源会有很多需要修改的地方，很容易遗漏导致安装失败，建议搭建proxy或者部署在能访问外网的环境中

1.3.1 购买ss服务

https://portal.shadowsocks.au/login

1.3.2 搭建trojan+privoxy实现科学上网

具体操作请看文档 Linux trojan proxy

注意：由于部分代理模式问题，导致开启了代理后在yum安装时会报503，所以需要对privoxy的forward做一些策略修改

将全转发策略 forward-socks5t / 127.0.0.1:1080 . 替换为

forward-socks5t .google.com 127.0.0.1:1080 .
forward-socks5t .googleapis.com 127.0.0.1:1080 .
forward-socks5t .githubusercontent.com 127.0.0.1:1080 .
forward-socks5t .github.com 127.0.0.1:1080 .
forward-socks5t .docker.io 127.0.0.1:1080 .
forward-socks5t .k8s.io 127.0.0.1:1080 .
forward-socks5t .pkg.dev 127.0.0.1:1080 .

只对这些地址做外部转发

编辑所有节点的/root/.bash_profile，添加环境变量设置命令行代理

export https_proxy=http://10.211.55.14:8118
export http_proxy=http://10.211.55.14:8118
export all_proxy=http://10.211.55.14:8118

注意：10.211.55.14为部署了trojan+privoxy可科学上网的代理服务器

加载配置

source /root/.bash_profile

2. 系统设置（所有节点）

注意：所有操作使用root用户执行

2.1 主机名

主机名必须合法，并且每个节点都不一样（建议命名规范：数字+字母+中划线组合，不要包含其他特殊字符）。

# 查看主机名

$ hostname

# 修改主机名

$ hostnamectl set-hostname

#### 2.2 关闭防火墙、selinux、swap，重置iptables

# 关闭selinux

$ setenforce 0 $ sed -i ‘/SELINUX/s/enforcing/disabled/’ /etc/selinux/config

# 关闭防火墙

$ systemctl stop firewalld && systemctl disable firewalld

# 设置iptables规则

$ iptables -F && iptables -X && iptables -F -t nat && iptables -X -t nat && iptables -P FORWARD ACCEPT

# 关闭swap

$ swapoff -a && free –h

# 关闭dnsmasq(否则可能导致容器无法解析域名)

$ service dnsmasq stop && systemctl disable dnsmasq

2.3 k8s参数设置

# 制作配置文件

$ cat > /etc/sysctl.d/kubernetes.conf <<EOF net.bridge.bridge-nf-call-ip6tables = 1 net.bridge.bridge-nf-call-iptables = 1 net.ipv4.ip_nonlocal_bind = 1 net.ipv4.ip_forward = 1 vm.swappiness = 0 vm.overcommit_memory = 1 EOF

# 生效文件

$ sysctl -p /etc/sysctl.d/kubernetes.conf

2.4 etcdV3 API环境变量设置

注意：使用etcd V3版本调用API时需要设置

# 编辑/etc/profile

$ vi /etc/profile

# 在文件尾部添加如下命令

export ETCDCTL_API=3

# 加载配置

$ source /etc/profile

2.5 移除docker相关软件包（可选）

$ yum remove -y docker* $ rm -f /etc/docker/daemon.json

3. 使用kubespray部署集群

这部分只需要在一个 操作 节点执行，可以是集群中的一个节点，也可以是集群之外的节点。甚至可以是你自己的笔记本电脑。我们这里使用更普遍的集群中的任意一个linux节点。

3.1 配置免密

# 1. 生成keygen（执行ssh-keygen，一路回车下去）

$ ssh-keygen

# 2. 查看并复制生成的pubkey

$ cat /root/.ssh/id_rsa.pub

# 3. 分别登陆到每个节点上，将pubkey写入/root/.ssh/authorized_keys

$ mkdir -p /root/.ssh $ echo “” >> /root/.ssh/authorized_keys

设置完成后在 操作 节点对每个节点使用ssh测试登录，不用输入密码即配置完成

3.2 依赖软件下载、安装

根据需要部署的k8s版本可下载对应的kubespray版本，建议下载最新版，本例使用目前最新的2.21.0版本，该版本支持最新的python3.11，后续我们也将采用这个版本的python进行部署

3.2.1 kubespray2.21.0对应的Component versions

• Core
  • kubernetes v1.25.6
  • etcd v3.5.6
  • docker v20.10 (cri_dockerd: v0.3.0)
  • containerd v1.6.15
  • cri-o v1.24
• Network Plugin
  • cni-plugins v1.2.0
  • calico v3.24.5
  • cilium v1.12.1
  • flannel v0.20.2
  • kube-ovn v1.10.7
  • kube-router v1.5.1
  • multus v3.8
  • weave v2.8.1
  • kube-vip v0.5.5
• Application
  • cert-manager v1.11.0
  • coredns v1.9.3
  • ingress-nginx v1.5.1
  • krew v0.4.3
  • argocd v2.5.7
  • helm v3.10.3
  • metallb v0.12.1
  • registry v2.8.1
• Storage Plugin
  • cephfs-provisioner v2.1.0-k8s1.11
  • rbd-provisioner v2.1.1-k8s1.11
  • aws-ebs-csi-plugin v0.5.0
  • azure-csi-plugin v1.10.0
  • cinder-csi-plugin v1.22.0
  • gcp-pd-csi-plugin v1.4.0
  • local-path-provisioner v0.0.22
  • local-volume-provisioner v2.5.0

3.2.2 CentOS 7 安装python3.11

安装过程比较繁琐，不在这里过多赘述，可以参考以下文章

CentOS 7 安装python3.11

注意：pip执行是需要ssl支持的，而python3.11需要openssl11，如果系统默认的openssl版本未更新，会导致编译后的python没有ssl模块

3.2.3 kubespray下载

kubespray github

# 下载部署包

wget https://github.com/kubernetes-sigs/kubespray/archive/refs/tags/v2.21.0.tar.gz

# 解压部署包

tar -xvf v2.21.0.tar.gz && cd kubespray-2.21.0

# 安装requirements

cat requirements.txt pip3 install -r requirements.txt

# 如果install遇到问题可以尝试升级pip，可能会遇到ruamel包无法安装

pip3 install –upgrade pip

注意：必须确保所有依赖包正确安装，不然部署过程会有莫名其妙问题导致失败

3.3 生成配置

项目中有一个目录是集群的基础配置，示例配置在目录inventory/sample中，我们复制一份出来作为自己集群的配置

cp -rpf inventory/sample inventory/mycluster

由于kubespray给我们准备了py脚本，可以直接根据环境变量自动生成配置文件，所以我们现在只需要设定好环境变量就可以啦

# 使用真实的hostname（否则会自动把你的hostname改成node1/node2…这种哦）

$ export USE_REAL_HOSTNAME=true

# 指定配置文件位置

$ export CONFIG_FILE=inventory/mycluster/hosts.yaml

# 定义ip列表（你的服务器内网ip地址列表，3台及以上，前两台默认为master节点）

$ declare -a IPS=(10.211.55.14 10.211.55.15 10.211.55.16)

# 生成配置文件

$ python3 contrib/inventory_builder/inventory.py ${IPS[@]}

3.4 个性化配置

配置文件都生成好了，虽然可以直接用，但并不能完全满足大家的个性化需求，比如用docker还是containerd？docker的工作目录是否用默认的/var/lib/docker？等等。当然默认的情况kubespray还会到google的官方仓库下载镜像、二进制文件，这个就需要你的服务器可以上外面的网，想上外网也需要修改一些配置。

3.4.1 节点组织配置（这里可以调整每个节点的角色）

[root@node-1 kubespray-2.21.0]# cat inventory/mycluster/hosts.yaml
all:
  hosts:
    node-1:
      ansible_host: 10.211.55.14
      ip: 10.211.55.14
      access_ip: 10.211.55.14
    node-2:
      ansible_host: 10.211.55.15
      ip: 10.211.55.15
      access_ip: 10.211.55.15
    node-3:
      ansible_host: 10.211.55.16
      ip: 10.211.55.16
      access_ip: 10.211.55.16
  children:
    kube_control_plane: ## master节点的主机
      hosts:
        node-1:
        node-2:
    kube_node:  ## worker节点的主机
      hosts:
        node-1:
        node-2:
        node-3:
    etcd:
      hosts:
        node-1:
        node-2:
        node-3:
    k8s_cluster:
      children:
        kube_control_plane:
        kube_node:
    calico_rr:
      hosts: {}

3.4.2 k8s集群配置（包括设置容器运行时、svc网段、pod网段等）

cat inventory/mycluster/group_vars/k8s_cluster/k8s-cluster.yml

根据需要修改相关配置，主要配置参考

## Change this to use another Kubernetes version, e.g. a current beta release kube_version: v1.25.6

网络插件，默认为calico，可根据实际需要配置

# Choose network plugin (cilium, calico, kube-ovn, weave or flannel. Use cni for generic cni plugin) # Can also be set to ‘cloud’, which lets the cloud provider setup appropriate routing kube_network_plugin: calico

service所在网段，默认为10.233.0.0/18，可以根据实际需要设置

# Kubernetes internal network for services, unused block of space. kube_service_addresses: 10.100.0.0/16

pod所在网段，默认为10.233.64.0/18，可根据实际需要设置

# internal network. When used, it will assign IP # addresses from this range to individual pods. # This network must be unused in your network infrastructure! kube_pods_subnet: 10.200.0.0/16

容器运行时，以前默认为docker，现在默认值为containerd

## Container runtime ## docker for docker, crio for cri-o and containerd for containerd. ## Default: containerd container_manager: containerd

3.4.3 containerd配置（本文使用containerd作为i容器引擎）

cat inventory/mycluster/group_vars/all/containerd.yml

---
# Please see roles/container-engine/containerd/defaults/main.yml for more configuration options

# containerd_storage_dir: "/var/lib/containerd"
# containerd_state_dir: "/run/containerd"
containerd_oom_score: -999 ##默认为0， 需要设置为-999防止被杀

# containerd_default_runtime: "runc"
# containerd_snapshotter: "native"

# containerd_runc_runtime:
#   name: runc
#   type: "io.containerd.runc.v2"
#   engine: ""
#   root: ""

# containerd_additional_runtimes:
# Example for Kata Containers as additional runtime:
#   - name: kata
#     type: "io.containerd.kata.v2"
#     engine: ""
#     root: ""

# containerd_grpc_max_recv_message_size: 16777216
# containerd_grpc_max_send_message_size: 16777216

# containerd_debug_level: "info"

# containerd_metrics_address: ""

# containerd_metrics_grpc_histogram: false

## An obvious use case is allowing insecure-registry access to self hosted registries.
## Can be ipaddress and domain_name.
## example define mirror.registry.io or 172.19.16.11:5000
## set "name": "url". insecure url must be started http://
## Port number is also needed if the default HTTPS port is not used.
# containerd_insecure_registries:
#   "localhost": "http://127.0.0.1"
#   "172.19.16.11:5000": "http://172.19.16.11:5000"

# containerd_registries:
#   "docker.io": "https://registry-1.docker.io"

# containerd_max_container_log_line_size: -1

# containerd_registry_auth:
#   - registry: 10.0.0.2:5000
#     username: user
#     password: pass

3.4.4 配置etcd部署类型（新版本默认是host，容器引擎是docker的需要修改为docker）

cat inventory/mycluster/group_vars/all/etcd.yml

---
## Directory where etcd data stored
etcd_data_dir: /var/lib/etcd

## Container runtime
## docker for docker, crio for cri-o and containerd for containerd.
## Additionally you can set this to kubeadm if you want to install etcd using kubeadm
## Kubeadm etcd deployment is experimental and only available for new deployments
## If this is not set, container manager will be inherited from the Kubespray defaults
## and not from k8s_cluster/k8s-cluster.yml, which might not be what you want.
## Also this makes possible to use different container manager for etcd nodes.
# container_manager: containerd

## Settings for etcd deployment type
# Set this to docker if you are using container_manager: docker
etcd_deployment_type: host

3.4.5 附加组件（ingress、dashboard等）

cat inventory/mycluster/group_vars/k8s_cluster/addons.yml

---
# Kubernetes dashboard
# RBAC required. see docs/getting-started.md for access details.
dashboard_enabled: true ##默认为false，如需要安装设置为true

# Helm deployment
helm_enabled: false

# Registry deployment
registry_enabled: false
# registry_namespace: kube-system
# registry_storage_class: ""
# registry_disk_size: "10Gi"

# Metrics Server deployment
metrics_server_enabled: false
# metrics_server_container_port: 4443
# metrics_server_kubelet_insecure_tls: true
# metrics_server_metric_resolution: 15s
# metrics_server_kubelet_preferred_address_types: "InternalIP,ExternalIP,Hostname"
# metrics_server_host_network: false
# metrics_server_replicas: 1

# Rancher Local Path Provisioner
local_path_provisioner_enabled: false
# local_path_provisioner_namespace: "local-path-storage"
# local_path_provisioner_storage_class: "local-path"
# local_path_provisioner_reclaim_policy: Delete
# local_path_provisioner_claim_root: /opt/local-path-provisioner/
# local_path_provisioner_debug: false
# local_path_provisioner_image_repo: "rancher/local-path-provisioner"
# local_path_provisioner_image_tag: "v0.0.22"
# local_path_provisioner_helper_image_repo: "busybox"
# local_path_provisioner_helper_image_tag: "latest"

# Local volume provisioner deployment
local_volume_provisioner_enabled: false
# local_volume_provisioner_namespace: kube-system
# local_volume_provisioner_nodelabels:
#   - kubernetes.io/hostname
#   - topology.kubernetes.io/region
#   - topology.kubernetes.io/zone
# local_volume_provisioner_storage_classes:
#   local-storage:
#     host_dir: /mnt/disks
#     mount_dir: /mnt/disks
#     volume_mode: Filesystem
#     fs_type: ext4
#   fast-disks:
#     host_dir: /mnt/fast-disks
#     mount_dir: /mnt/fast-disks
#     block_cleaner_command:
#       - "/scripts/shred.sh"
#       - "2"
#     volume_mode: Filesystem
#     fs_type: ext4
# local_volume_provisioner_tolerations:
#   - effect: NoSchedule
#     operator: Exists

# CSI Volume Snapshot Controller deployment, set this to true if your CSI is able to manage snapshots
# currently, setting cinder_csi_enabled=true would automatically enable the snapshot controller
# Longhorn is an extenal CSI that would also require setting this to true but it is not included in kubespray
# csi_snapshot_controller_enabled: false
# csi snapshot namespace
# snapshot_controller_namespace: kube-system

# CephFS provisioner deployment
cephfs_provisioner_enabled: false
# cephfs_provisioner_namespace: "cephfs-provisioner"
# cephfs_provisioner_cluster: ceph
# cephfs_provisioner_monitors: "172.24.0.1:6789,172.24.0.2:6789,172.24.0.3:6789"
# cephfs_provisioner_admin_id: admin
# cephfs_provisioner_secret: secret
# cephfs_provisioner_storage_class: cephfs
# cephfs_provisioner_reclaim_policy: Delete
# cephfs_provisioner_claim_root: /volumes
# cephfs_provisioner_deterministic_names: true

# RBD provisioner deployment
rbd_provisioner_enabled: false
# rbd_provisioner_namespace: rbd-provisioner
# rbd_provisioner_replicas: 2
# rbd_provisioner_monitors: "172.24.0.1:6789,172.24.0.2:6789,172.24.0.3:6789"
# rbd_provisioner_pool: kube
# rbd_provisioner_admin_id: admin
# rbd_provisioner_secret_name: ceph-secret-admin
# rbd_provisioner_secret: ceph-key-admin
# rbd_provisioner_user_id: kube
# rbd_provisioner_user_secret_name: ceph-secret-user
# rbd_provisioner_user_secret: ceph-key-user
# rbd_provisioner_user_secret_namespace: rbd-provisioner
# rbd_provisioner_fs_type: ext4
# rbd_provisioner_image_format: "2"
# rbd_provisioner_image_features: layering
# rbd_provisioner_storage_class: rbd
# rbd_provisioner_reclaim_policy: Delete

# Nginx ingress controller deployment
ingress_nginx_enabled: true ##默认为false，如需要安装设置为true
# ingress_nginx_host_network: false
ingress_publish_status_address: ""
# ingress_nginx_nodeselector:
#   kubernetes.io/os: "linux"
# ingress_nginx_tolerations:
#   - key: "node-role.kubernetes.io/master"
#     operator: "Equal"
#     value: ""
#     effect: "NoSchedule"
#   - key: "node-role.kubernetes.io/control-plane"
#     operator: "Equal"
#     value: ""
#     effect: "NoSchedule"
# ingress_nginx_namespace: "ingress-nginx"
# ingress_nginx_insecure_port: 80
# ingress_nginx_secure_port: 443
# ingress_nginx_configmap:
#   map-hash-bucket-size: "128"
#   ssl-protocols: "TLSv1.2 TLSv1.3"
# ingress_nginx_configmap_tcp_services:
#   9000: "default/example-go:8080"
# ingress_nginx_configmap_udp_services:
#   53: "kube-system/coredns:53"
# ingress_nginx_extra_args:
#   - --default-ssl-certificate=default/foo-tls
# ingress_nginx_termination_grace_period_seconds: 300
# ingress_nginx_class: nginx

# ALB ingress controller deployment
ingress_alb_enabled: false
# alb_ingress_aws_region: "us-east-1"
# alb_ingress_restrict_scheme: "false"
# Enables logging on all outbound requests sent to the AWS API.
# If logging is desired, set to true.
# alb_ingress_aws_debug: "false"

# Cert manager deployment
cert_manager_enabled: false
# cert_manager_namespace: "cert-manager"
# cert_manager_tolerations:
#   - key: node-role.kubernetes.io/master
#     effect: NoSchedule
#   - key: node-role.kubernetes.io/control-plane
#     effect: NoSchedule
# cert_manager_affinity:
#  nodeAffinity:
#    preferredDuringSchedulingIgnoredDuringExecution:
#    - weight: 100
#      preference:
#        matchExpressions:
#        - key: node-role.kubernetes.io/control-plane
#          operator: In
#          values:
#          - ""
# cert_manager_nodeselector:
#   kubernetes.io/os: "linux"

# cert_manager_trusted_internal_ca: |
#   -----BEGIN CERTIFICATE-----
#   [REPLACE with your CA certificate]
#   -----END CERTIFICATE-----
# cert_manager_leader_election_namespace: kube-system

# MetalLB deployment
metallb_enabled: false
metallb_speaker_enabled: "{{ metallb_enabled }}"
# metallb_ip_range:
#   - "10.5.0.50-10.5.0.99"
# metallb_pool_name: "loadbalanced"
# metallb_auto_assign: true
# metallb_avoid_buggy_ips: false
# metallb_speaker_nodeselector:
#   kubernetes.io/os: "linux"
# metallb_controller_nodeselector:
#   kubernetes.io/os: "linux"
# metallb_speaker_tolerations:
#   - key: "node-role.kubernetes.io/master"
#     operator: "Equal"
#     value: ""
#     effect: "NoSchedule"
#   - key: "node-role.kubernetes.io/control-plane"
#     operator: "Equal"
#     value: ""
#     effect: "NoSchedule"
# metallb_controller_tolerations:
#   - key: "node-role.kubernetes.io/master"
#     operator: "Equal"
#     value: ""
#     effect: "NoSchedule"
#   - key: "node-role.kubernetes.io/control-plane"
#     operator: "Equal"
#     value: ""
#     effect: "NoSchedule"
# metallb_version: v0.12.1
# metallb_protocol: "layer2"
# metallb_port: "7472"
# metallb_memberlist_port: "7946"
# metallb_additional_address_pools:
#   kube_service_pool:
#     ip_range:
#       - "10.5.1.50-10.5.1.99"
#     protocol: "layer2"
#     auto_assign: false
#     avoid_buggy_ips: false
# metallb_protocol: "bgp"
# metallb_peers:
#   - peer_address: 192.0.2.1
#     peer_asn: 64512
#     my_asn: 4200000000
#   - peer_address: 192.0.2.2
#     peer_asn: 64513
#     my_asn: 4200000000

argocd_enabled: false
# argocd_version: v2.5.7
# argocd_namespace: argocd
# Default password:
#   - https://argo-cd.readthedocs.io/en/stable/getting_started/#4-login-using-the-cli
#   ---
#   The initial password is autogenerated to be the pod name of the Argo CD API server. This can be retrieved with the command:
#   kubectl get pods -n argocd -l app.kubernetes.io/name=argocd-server -o name | cut -d'/' -f 2
#   ---
# Use the following var to set admin password
# argocd_admin_password: "password"

# The plugin manager for kubectl
krew_enabled: false
krew_root_dir: "/usr/local/krew"

3.4.6 全局配置（可以在这配置http(s)代理实现外网访问）

cat inventory/mycluster/group_vars/all/all.yml

---
## Directory where the binaries will be installed
bin_dir: /usr/local/bin

## The access_ip variable is used to define how other nodes should access
## the node.  This is used in flannel to allow other flannel nodes to see
## this node for example.  The access_ip is really useful AWS and Google
## environments where the nodes are accessed remotely by the "public" ip,
## but don't know about that address themselves.
# access_ip: 1.1.1.1

## External LB example config
## apiserver_loadbalancer_domain_name: "elb.some.domain"
# loadbalancer_apiserver:
#   address: 1.2.3.4
#   port: 1234

## Internal loadbalancers for apiservers
# loadbalancer_apiserver_localhost: true
# valid options are "nginx" or "haproxy"
# loadbalancer_apiserver_type: nginx  # valid values "nginx" or "haproxy"

## If the cilium is going to be used in strict mode, we can use the
## localhost connection and not use the external LB. If this parameter is
## not specified, the first node to connect to kubeapi will be used.
# use_localhost_as_kubeapi_loadbalancer: true

## Local loadbalancer should use this port
## And must be set port 6443
loadbalancer_apiserver_port: 6443

## If loadbalancer_apiserver_healthcheck_port variable defined, enables proxy liveness check for nginx.
loadbalancer_apiserver_healthcheck_port: 8081

### OTHER OPTIONAL VARIABLES

## By default, Kubespray collects nameservers on the host. It then adds the previously collected nameservers in nameserverentries.
## If true, Kubespray does not include host nameservers in nameserverentries in dns_late stage. However, It uses the nameserver to make sure cluster installed safely in dns_early stage.
## Use this option with caution, you may need to define your dns servers. Otherwise, the outbound queries such as www.google.com may fail.
# disable_host_nameservers: false

## Upstream dns servers
# upstream_dns_servers:
#   - 8.8.8.8
#   - 8.8.4.4

## There are some changes specific to the cloud providers
## for instance we need to encapsulate packets with some network plugins
## If set the possible values are either 'gce', 'aws', 'azure', 'openstack', 'vsphere', 'oci', or 'external'
## When openstack is used make sure to source in the openstack credentials
## like you would do when using openstack-client before starting the playbook.
# cloud_provider:

## When cloud_provider is set to 'external', you can set the cloud controller to deploy
## Supported cloud controllers are: 'openstack', 'vsphere' and 'hcloud'
## When openstack or vsphere are used make sure to source in the required fields
# external_cloud_provider:

## Set these proxy values in order to update package manager and docker daemon to use proxies
http_proxy: "http://10.211.55.14:8118"  ##需要设置为环境中配置了privoxy的代理地址
https_proxy: "http://10.211.55.14:8118"

## Refer to roles/kubespray-defaults/defaults/main.yml before modifying no_proxy
# no_proxy: ""

## Some problems may occur when downloading files over https proxy due to ansible bug
## https://github.com/ansible/ansible/issues/32750. Set this variable to False to disable
## SSL validation of get_url module. Note that kubespray will still be performing checksum validation.
# download_validate_certs: False

## If you need exclude all cluster nodes from proxy and other resources, add other resources here.
# additional_no_proxy: ""

## If you need to disable proxying of os package repositories but are still behind an http_proxy set
## skip_http_proxy_on_os_packages to true
## This will cause kubespray not to set proxy environment in /etc/yum.conf for centos and in /etc/apt/apt.conf for debian/ubuntu
## Special information for debian/ubuntu - you have to set the no_proxy variable, then apt package will install from your source of wish
skip_http_proxy_on_os_packages: true ##yum安装os包时不启用代理，否则会直接将代理地址设置到yum.conf中

## Since workers are included in the no_proxy variable by default, docker engine will be restarted on all nodes (all
## pods will restart) when adding or removing workers.  To override this behaviour by only including master nodes in the
## no_proxy variable, set below to true:
no_proxy_exclude_workers: false

## Certificate Management
## This setting determines whether certs are generated via scripts.
## Chose 'none' if you provide your own certificates.
## Option is  "script", "none"
# cert_management: script

## Set to true to allow pre-checks to fail and continue deployment
# ignore_assert_errors: false

## The read-only port for the Kubelet to serve on with no authentication/authorization. Uncomment to enable.
# kube_read_only_port: 10255

## Set true to download and cache container
# download_container: true

## Deploy container engine
# Set false if you want to deploy container engine manually.
# deploy_container_engine: true

## Red Hat Enterprise Linux subscription registration
## Add either RHEL subscription Username/Password or Organization ID/Activation Key combination
## Update RHEL subscription purpose usage, role and SLA if necessary
# rh_subscription_username: ""
# rh_subscription_password: ""
# rh_subscription_org_id: ""
# rh_subscription_activation_key: ""
# rh_subscription_usage: "Development"
# rh_subscription_role: "Red Hat Enterprise Server"
# rh_subscription_sla: "Self-Support"

## Check if access_ip responds to ping. Set false if your firewall blocks ICMP.
# ping_access_ip: true

# sysctl_file_path to add sysctl conf to
# sysctl_file_path: "/etc/sysctl.d/99-sysctl.conf"

## Variables for webhook token auth https://kubernetes.io/docs/reference/access-authn-authz/authentication/#webhook-token-authentication
kube_webhook_token_auth: false
kube_webhook_token_auth_url_skip_tls_verify: false
# kube_webhook_token_auth_url: https://...
## base64-encoded string of the webhook's CA certificate
# kube_webhook_token_auth_ca_data: "LS0t..."

## NTP Settings
# Start the ntpd or chrony service and enable it at system boot.
ntp_enabled: false
ntp_manage_config: false
ntp_servers:
  - "0.pool.ntp.org iburst"
  - "1.pool.ntp.org iburst"
  - "2.pool.ntp.org iburst"
  - "3.pool.ntp.org iburst"

## Used to control no_log attribute
unsafe_show_logs: false

3.5 一键部署

配置文件都调整好了后，就可以开始一键部署啦，不过部署过程不出意外会非常慢。

一键部署

需要使用root用户执行ansible-playbook –become参数是必须的，例如在/etc中写入SSL Key 没有become参数，playbook将运行失败 -vvvv会打印最详细的日志信息，建议开启

ansible-playbook -i inventory/mycluster/hosts.yaml –become –become-user=root cluster.yml -vvvv

经过漫长的等待后，如果没有问题，整个集群都部署起来啦

3.6 清理代理设置

清理代理设置（运行时不再需要代理，删掉代理配置即可）

删除docker的http代理（在每个节点执行）

$ rm -f /etc/systemd/system/containerd.service.d/http-proxy.conf $ systemctl daemon-reload $ systemctl restart containerd

删除yum代理（如果之前没有配置skip_http_proxy_on_os_packages: true）

# 把grep出来的代理配置手动删除即可

$ grep 8118 -r /etc/yum*

删除.bash_profile中代理配置（在每个节点执行）
